Santa Cruz Bicycles was released in 1993 in Santa Cruz, California.
A mountain bike maker born from a small garage in the Seabright Cannery.

Chameleon, a model that can be said to represent Santa Cruz, enjoys the trail and
And an aluminum hard tail for aggressive enjoyment.

The recommended travel for the front suspension is 120mm.

The rear end adopts the boost standard and the rear center can be changed by the adjuster.
Furthermore, by exchanging the rear end, you can enjoy it as 27.5 plus, 29er or even single speed.

When using it as a plus bike, the rear wheel clearance is large, so swallow 27.5X3.0 plus tires as well.

A 1x system is recommended for the drive system, but a direct mount front derailleur can also be used.

【SPEC】

headset	Because it is Integrated (IS41 / 52)CHRIS KING DropSet1Can be used
Seatpost diameter	31.9mm
Seat clamp diameter	36.4mm
BB shell width	73mm thread type
Corresponding tire size	29x2.5" / 27.5x3.0"
Rear end	148mm Boost standard / variable type supports single speed

【GEOMETRY】

29 "value for wheel / (value for 27.5" + in parentheses)

		S	M	L	XL
A	reach	412mm (411mm)	437mm (436mm)	460mm (456mm)	487mm (486mm)
B	stack	617mm (618mm)	617mm (618mm)	625mm (628mm)	626mm (637mm)
C	Head tube angle	67.3° (67.1°)	67.3° (67.1°)	67.3° (67.1°)	67.3° (67.1°)
D	Head tube length	390mm	420mm	450mm	490mm
AND	Front Center	703mm (707mm)	728mm (732mm)	748mm (756mm)	782mm (790mm)
F	BB height	315mm	315mm	315mm	315mm
G	BB Drop	55mm (47mm)	55mm (47mm)	55mm (47mm)	55mm (47mm)
H	Wheelbase	1115mm (1119mm)	1140mm (1144mm)	1160mm (1167mm)	1194mm (1201mm)
I	Chain stay length	415-430mm	415-430mm	415-430mm	415-430mm
J	Head tube length	100mm	100mm	110mm	120mm
K	Top tube length	601mm (598mm)	626mm (623mm)	649mm (647mm)	682mm (680mm)
L	Head tube angle	72.8° (72.6°)	72.8° (72.6°)	72.8° (72.6°)	72.8°(72.6°)
M	Standover height	689mm (686mm)	696mm (702mm)	721mm (719mm)	740mm (738mm)
