This is an unused, scratched B grade item. Returns and exchanges will not be accepted.
Scratches on the top and bottom of the clamp.

NITTO' s Mod 177 is a drop bar that is known and loved all over the world as the Noodle Bar, a bar shape that even riders who already love drop bars will fall in love with. It is an excellent drop bar that can even capture the hearts of riders who think that drop bars are a bit too much for their liking.

The Noodle Bar may be the most comfortable drop bar for any cyclist. Its shaping is such that the flat part at the top sweeps back slightly toward the rider, bringing the bar closer, and the drop (bottom) flares out 4°. But the important part is the ramp just behind the bar, where the brake lever fits. Many riders place their hands there, and if the slope is too steep, there is no support and the hands can slide forward or down.

Most bars have a slope of about 24° to 32°, but the Noodle Bar has a slope of 15°. If you tilt the bar properly so that the ends face downward about 10°, the 15° slope becomes 5°, so even if your hands are sweaty, you won't slip down from there.

When choosing the width of this noodle bar, it is not recommended that it be as wide as your shoulder width like a regular handlebar. A bar size slightly wider than shoulder width would be better.

Made in Japan by NITTO
Designed by Rivendell U.S.A.

[SPEC].

Width : 460mm
Clamp Diameter : φ26.0mm
Handle Diameter : φ24.0mm
Drop : 140mm
Reach : 95mm
Bar End Inner Diameter : Approx. 20mm
Material : Aluminum (460mm and over are heat treated for strength.)
