[In-Stock] OMNIUM Cargo V3 Frame Kit

[In-Stock] OMNIUM Cargo V3 Frame Kit

Copperhead / Small / 142 x 12 TA
¥327,800
Skip to product information
[In-Stock] OMNIUM Cargo V3 Frame Kit

[In-Stock] OMNIUM Cargo V3 Frame Kit

OMNIUM
SKU: OM-CA-CO-S-TA-Stock
¥327,800
Taxes included. Shipping calculated at checkout.
Color
Size
Dropout
Check your size based on your height

Check your size based on your height

Shows size options that fit your height. Fit can vary with proportions, riding style, and position, so please use this as a general guide.

Size options —

Sizing can change with riding style and position. If you are near a boundary, please contact Circles.

This item is out of stock and will be ordered in for you. Delivery will take longer than usual.

Ask about stock and delivery

このフレームで、一台を組んでみませんか?
ハンドルもホイールも、自分らしい組み合わせで。サイズ選びからお手伝いします。

完成車の組み立て・サイズを相談する → 上のカートはフレームセット単体のご購入です。完成車の組み立ては別途お見積もりします。

*This item is in stock and ready to ship.
*This item is sold as a frame set.
*The "Blurple" and "Pirate Black" colors carry an additional charge of 22,000 yen.

The ultimate cargo bike, built by messengers

Based in Copenhagen, Denmark, OMNIUM makes fast, light and stable cargo bikes for carrying loads, getting around and traveling.

The Cargo has been refined again and again based on feedback from bicycle messengers, and its agility and carrying capacity are proven. The Cargo V3 keeps the fast, nimble ride of earlier models and adds adjustable rocker dropouts, combining wide tires, reliable thru axles and new functional dropouts into the ultimate cargo bike built with versatility first.

The adjustable rocker dropouts let you choose from a range of drivetrains, from derailleur gears to internal gear hubs and belt drive (sadly not all at once...). Fixed gear works too! Interchangeable inserts let you choose between thru axle and quick release to suit your rear spacing and gear components. If needed, you can carry a spare set to quickly replace a broken gear hanger. Replacement dropout inserts are available here.

The Cargo is an incredibly versatile, light and fast cargo bike. Best of all, thanks to its clever construction and refined geometry, it rides like a normal bike when unloaded.

It has the longest wheelbase in the range, yet handles very steadily. The load sits between the front wheel and the kickstand, and the long wheelbase also adds stability when you load the rack yourself.

Going to buy a new sofa on your OMNIUM Cargo? Easy! Taking the kids to daycare before work? No problem! Pack your work laptop and gym clothes in a waterproof duffel and you're set all year round, rain or shine. Start a new life with a cargo bike!

[SPEC]

Size : XS, S, M, L, XL
Material : Double-Butted Chromoly Steel Frame & Fork
Seat Post diam. : 31.6mm
Seat Clamp Size : 34.0 mm
Front Wheel : 20" (etrto 406) / TA 15 x 100 mm spacing, Disc Brake only
Rear Wheel : TA Insert : 700c (etrto 622) / 12 x 142mm spacing, Disc Brake only
QR Insert : 700c (etrto 622) / 10 x 135mm spacing, Disc Brake only
Front Tire Clearance : 55mm with mudguards
Rear Tire Clearance : 55mm with mudguards
Front Thru Axle : 15×100, 125mm long, 17mm thread length, 1.5mm pitch
Rear Thru Axle : 12×142, 172mm long, 19mm thread length, 1.75mm pitch
Fork Headset : 1-1/8″ Threaded Integrated with locking cap
Steerer Headset : 1-1/8″ Ahead
Bottom Bracket : 68mm BSA
Brake Mounts : IS brake mount front and rear, for minimum 160mm and max 180 rotors
Q-Factor : 145mm
Gears : For 1x rear derailleur gear system
Standard Rack Weight : 1,320g +/-
Rack Dimensions : 83cm x 50cm
Rack Bolt Size : M15 x 15mm
Weight : Complete Medium bike weighs 20kg
Maximum Loading Weight On Front Rack 85.0kg
Maximum Total Loading Weight Including Rider : 175.0kg


Frame kit includes
  • Frame
  • Fork
  • Headset
  • Steering rod
  • Steerer tube
  • Seat clamp
  • Front rack
  • Front and rear thru axles
*Headset spacers and kickstand are not included.


[SIZE GUIDE]

Rider height Recommended frame size
155 - 165cm X-Small
165 - 175cm Small
175 - 185cm Medium
185 - 195cm Large
195 - 205cm X-Large


[GEOMETRY]

Cargo V3 XS (49.5) S (52) M (54.5) L (57) XL (60)
Seat Tube (Center - Top) (mm) 495 520 545 570 600
Actual Top Tube (Center - Center) (mm) 505 520 545 570 600
Stack Height (mm) 533 557 581 605.5 634
Reach (mm) 349 357 375 394 415
Stand Over Height (mm) 745 769.5 793.5 818 846
Bottom Bracket Height (mm) 288 288 288 288 288
Bottom Bracket Drop (mm) 81 81 81 81 81
Seat Tube Angle 74° 74° 74° 74° 74
Head Tube Angle Rear 74.5° 74.7° 75° 75.4° 75.5°
Head Rube Angle Front 74.5° 74.6° 74.9° 75.4° 75.5°
Wheel Base (mm) 1,578 1,590 1,612 1,632 1,657
Axle to Crown (mm) 298.5 298.5 298.5 298.5 298.5
Rake (mm) 45 45 45 45 45
Trail (mm) 25.5 25 23.5 24 21
Chain Stay Length (mm) 462 462 462 462 462
Full Bike Length (mm) 2,208 2,220 2,241 2,262 2,286
