SIMWORKS Bubbly Pedal

SimWorks by MKS, the first installment of the march!

The endless, roadless road. Long tourer's pedaling stress is converted into pedaling happiness by the Bubbly Effect. The more you pedal, the happier you will be....

Of the elements that make up a bicycle, there are only four rotating parts with bearings: the hub, headset, bottom bracket, and pedals. In the simple structure of a bicycle, no compromises can be made in any of these parts.

Bubbly 's triple shielded bearings are mainly used in the NEXT grade pedals of the Sylvan series, the face of MKS. The spindle (pedal shaft) must be thicker and stronger on the inside to support the rider's weight. This means that the outer shape of the inner bearing tends to be larger than the outer shape of the outer bearing, but the triple shielded bearing mechanism increases the number of inner bearings to two and reduces the stack height (thickness from the center of the shaft to the tread) of the pedal by reducing the outer shape while distributing the load.

The tread surface is one of the largest in the MKS pedals. The key point is not only the area but also the shape of the concave that fits the sole. The tread is designed to be concave around the axis of rotation, boldly shaped in the front-back direction and slightly mortar-shaped in the sideways direction, so please place your foot on it with this in mind. Your foot should be placed in the position where you feel most comfortable. Moreover, this position always changes slightly depending on the road surface, shoes, and riding conditions, but with the Babbly pedals, you will always feel that the soles of your feet are in a comfortable position under any circumstances.

The rider has only three points of contact with the bike: the grip, the saddle, and the pedals, so the longer the ride, the more uncompromising these comfort features become. Once you have reached the comfort of the Bubbly pedals, which are 10cm square per foot, you can concentrate on choosing the right ingredients for your burrito for the duration of the ride.

[FEATURE]

• Ultra-wide Concave Platform
  MKS The largest platform in MKS history, plus concave treads that curve like a plate to keep your feet in a comfortable position and reduce stress on long rides.
• Triple Sealed Bearing
  The structure has three bearing supports to maximize rotational performance while minimizing stack height, thereby reducing rotational resistance to the extreme.
• Chrome Plated Forged Spindle
  The spindle is cold forged and even the threads are cold rolled to ensure high precision and durability. Finished with chrome plating for the ultimate in durability.
• Made in Japan by MKS Pedal


[SPEC]

Size: 97 x 108 x 30mm
Weight: 392g (pair)
Body Material: Aluminum Alloy
Plate Material: Heat-treated Aluminum + Anodized
Spindle Material: Cold Forged Steel + Chrome Plated

Please click here to see our inventory of side plates for repair.
Please contact us for mail order.
