A chromoly gravel bike that handles both touring and gravel riding
Founded in 1988 and based in Fern Dale, Washington, USA, and Vancouver, British Columbia, Canada, KONA is a North American brand brimming with a free-spirited mindset that embraces the motto “Let’s enjoy cycling life!” rather than prioritizing racing above all else.
Born from KONA’s “FREE RANGE BIKE” concept, the ROVE
a series that can be seen as a symbol of foresight, having introduced the “touring gravel” style long before the term “gravel” became mainstream.
The ROVE ST is a chromoly frame model thatsmoothly absorbs road vibrations,delivers a comfortable ride that reduces fatigue even on long-distance rides, andoffers a smooth ride. For the 2026 model,the wheels have been updated from the traditional 650b to 700c, achieving higher cruising performance and versatility. The switch to flat-mount brakes achieves both a clean look and high stiffness. Combined with the newly equipped Shimano CUES 1×10-speed drivetrain, it delivers reliable braking power and smooth shifting in every scenario, from city riding to gravel.
The 16°-flared KONA gravel handlebars enhance control on descents and rough terrain, while the Maxxis Rambler 700×40c tubeless-ready tires support riding on any surface, from pavement to gravel.From commuting to school or work, to bike packing with gear, to long weekend rides, the Rove ST is a sophisticated, all-around gravel bike equipped with everything you need to comfortably cover long distances.
*Pedals not included
[SPEC]
| FRAME MATERIAL | Kona Butted Cromoly |
|---|---|
| SIZES | 48, 50, 52, 54 |
| Rear Shock | n/a |
| Fork | Kona Cromoly |
| Crankset | Shimano CUES 6030 40t / 48 165mm / 50 170mm / 52-54 172.5mm |
| Bottom Bracket | Shimano BSA 68 |
| Pedals | n/a |
| Chain | Shimano CUES LG500 |
| Cassette | Shimano CUES LG300 11-48t 10-speed |
| Chain guide | n/a |
| Front Derailleur | n/a |
| R/D | Shimano CUES 6000 |
| Shifters | Shimano CUES 6030 |
| Brake Calipers | Shimano CUES 6030 |
| Front Brake Rotor | Shimano 180mm 6B |
| Rear Brake Rotor | Shimano 180mm 6B |
| Brake Levers | Shimano CUES 6030 |
| Headset | FSA Orbit No.1 EC34/EC34 |
| Handlebar | Kona Gravel Dropbar 31.8mm / Width 48 42cm / 50-52 44cm / 54 46cm |
| Stem | Kona 31.8mm / Rise 6° / Length 48-52 60mm / 54 70mm |
| Seatpost | Kona w/Offset 27.2mm / 48-52 350mm / 54 375mm |
| Seat Clamp | Kona Clamp 31.8mm |
| Grips | Kona Cork Tape |
| Saddle | Kona Gravel |
| Front Hub | Formula 12x100mm |
| Rear Hub | Formula 12x142mm HG |
| Spokes | Stainless 2mm Black |
| Rims | WTB ST i23 TCS 2.0 |
| Front Tire | Maxxis Rambler 700x40mm |
| Rear Tire | Maxxis Rambler 700x40mm |
| Paint Color | Gloss Faux Chrome with Dark Concrete & Blue Smoke Decals |
[GEOMETRY]
| Size | 48 | 50 | 52 | 54 | |
|---|---|---|---|---|---|
| 1 | ST Length | 480 | 500 | 520 | 540 |
| 2 | TT Length | 524 | 539 | 554 | 570 |
| 3 | Reach | 380 | 385 | 390 | 395 |
| 4 | Stack | 536 | 555 | 573 | 592 |
| 5 | Standover | 749 | 769 | 790 | 809 |
| 6 | HT Angle | 69.5 | 69.5 | 70 | 70 |
| 7 | HT Length | 90 | 110 | 130 | 150 |
| 8 | ST Angle | 75.0 | 74.5 | 74.0 | 73.5 |
| 9 | CS Length | 435 | 435 | 435 | 435 |
| 10 | BB Drop | 74 | 74 | 72 | 72 |
| 11 | BB Height | 281 | 281 | 283 | 283 |
| 12 | Wheelbase | 1035 | 1047 | 1055 | 1066 |
| 13 | Front Center | 611 | 623 | 630 | 641 |
| 14 | Fork Length | 410 | 410 | 410 | 410 |
| 15 | Fork Offset | 50 | 50 | 50 | 50 |

[Recommended Height]
|
Height |
Inseam |
Size |
|
158–163 cm |
70–73 cm |
48 cm |
|
163–168 cm |
73–76 cm |
50 cm |
|
168–173 cm |
76–79 cm |
52 cm |
|
173–178 cm |
79–82 cm |
54 cm |
|
178–183 cm |
82–85 cm |
56 cm |
