OMNIUM Mini V3 Frame Kit

OMNIUMSKU: OM-M-CO-XS-TA

Color: Copperhead
Size: X-Small
Dropout: 142 x 12TA

Description

The product is ordered from the home country, so the delivery time is two to six months. Please note that we may not be able to order the product depending on the stock situation, in which case we will contact you individually.

A versatile cargo bike that shines in the city

Based in Copenhagen, Denmark, the OMNIUM brand manufactures lightweight, fast, and stable cargo bikes for carrying, moving, and traveling.

Designed with 55mm (2.15") tires as standard, the Omnium Mini is the ultimate cargo bike, combining a reliable through-axle with new high-performance dropouts.
Able to perform well in Japan, where roads and bike parking spaces are tight, the Mini V3 is the perfect balance of small size, load capacity, and easy handling in this series.

Adjustable rocker dropouts allow for a variety of drivetrain options, from exterior gears with derailleurs to interior gears or belt drive. It can also be set to fixed gears, although this may be very difficult.
Interchangeable inserts allow you to choose between through-axle or quick-release, depending on the rear hub end width and gear component selection. We recommend carrying a spare set so that you can easily replace a rear hanger that breaks due to long trips or use in extreme conditions.

Replacement dropout inserts can be ordered here.

Adjustable rocker dropouts are available as a free replacement when you purchase a frame kit.
Please select either:

  • 10 x 135 QR with IS brake mount - for internal gear hub or QR rear hub.
  • 12 x 142 thru-axle with IS brake mounts - for thru-axle hubs

All forks are 15 x 100 thru-axle regardless of dropout selection.

The ride and handling of the Mini V3 is truly that of a normal bike. Despite its large front carrier, its manageable size provides comfortable handling and allows it to carry multiple loads with ease.
Because the rack support is built directly into the frame, the weight and size of the load has little effect on the steering, allowing the bike to ride with surprising stability.

We believe that the Omnium is a bicycle that is full of playfulness and will make the future around us much brighter and more fun!

*The "Blurple" and "Pirate Black" colors will incur an up-charge of +22,000 yen.

[SPEC]

FRAME MATERIAL Double-Butted Chromoly Steel Frame
5 SIZES XS, S, M, L, XL
GEARS For 1x rear derailleur gear system
SEAT POST DIAMETER 31.6 mm
SEAT POST CLAMP SIZE 34.0 mm
REAR WHEEL TA Insert: 622, 12 x 142mm spacing, disc only
QR Insert: 622, 10 x 135mm spacing, disc only
FRONT WHEEL 406, 15 x 100 mm spacing, disc only
TYRE CLEARANCE, FRONT 55 mm with mudguards
TYRE CLEARANCE, REAR 55 mm with mudguards
THRU AXLE REAR 12×142, 172mm long, 19mm thread length, 1.75mm pitch
THRU AXLE FRONT 15×100, 125mm long, 17mm thread length, 1.5mm pitch
BOTTOM BRACKET BSA 68mm
STEERER HEADSET 1 1/8″ Ahead
Q-FACTOR/STANCE RACK DIMENSIONS
RACK DIMENSIONS 40cm x 42cm, made of Aluminum
STANDARD RACK WEIGHT 1320g +/-
RACK BOLT SIZE M8 x 15mm
WEIGHT Complete medium bike weighs 18kg
MAXIMUM TOTAL LOADING WEIGHT INCL. RIDER RIDER 125 kg

FRAMEKIT INCLUDES - Frame
- Fork
- Headsets (front and rear)
- Steering rod
- Steerer tube
- Seat clamp
- Rack
- Thru axles front
- Comes with a choice of qr dropouts ore 12mm thru axle dropouts and thru axle

Fork comes with 15x100 thru axle

Spacers for headset and kickstand are not included.

[SIZE GUIDE]

height: 155 - 165cm - recommended frame size - size X-Small
height: 165 - 175cm - recommended frame size size Small
Height: 175 - 185cm - Recommended frame size - size Medium
Height: 185 - 195cm - Recommended frame size - size Large
Height: 195 - 205cm - recommended frame size - size X-Large

[GEOMETRY]

Mini V3 XS (49.5) S (52) M (54.5) L (57) XL (60)
STL - seat tube length (c-t) 495 520 540 570 600
TTL - top tube length (c-c / actual) 505 520 540 570 570 Stack
Stack 528 Stack 528 572 601.5 601.5
Reach 347 355 369 390.5 SO - standover height
SO - standover height 743 767 786.5 815.5 844
BBH - bottom bracket height 288 288 288 288 288 288 BBD - bottom bracket drop
BBD - bottom bracket drop 81 81 81 81 81 81
STA - seat tube angle 73.3 73.5 73.5 73.5 73.5
HTA1 - head tube angle rear 73.5 73.5 73.5 73.5 73.5 73.5 73.5
WB - wheelbase 992 1006.5 1026.5 1057 1086
A-C - axle to crown 298,5 298 298 298 298 298 298 298
R - rake 26 26 26 26 26 R - rake 26 26 26
T - trail 49.5 49.5 49.5 49.6 49.7
CSL - chainstay length 462 462 462 462 462 462 462 462 462
FL - full bike length 1621.2 1636 1656 1686.5 1715.5
